The MFD test indications are as follows:
− Indications removed: heading source, TCAS, weather patch,
drift bug, wind vector, heading select bug, flight plan data,
airports, navaids, designator information.
− Indications forced: TERRAIN FAIL, EICAS CHK, WX TERRAIN,
MENU INOP, HDG FAIL.
− Indications presented as invalid: heading, weather radar tilt,
SAT, true airspeed, ground speed, distance and time to
waypoint.
