4 - RADIO ALTITUDE MINIMUM ALTITUDE ANNUNCIATOR
− When actual radio altitude decreases to within 100 ft of the set
Decision Height value, a white box is displayed. When the
actual radio altitude is equal to or less than the set value, MIN is
displayed in amber (inside the box) and it flashes for 10s.
5 - MARKER BEACON ANNUNCIATOR
− A cyan O represents the outer, an amber M represents the
middle, and a white I represents the inner marker. They appear
inside a white box, flashing.
6 - RADIO ALTITUDE MINIMUM ALTITUDE ANNUNCIATOR
− An amber MIN is displayed (boxed) and flashes for 10 seconds
when the actual radio altitude is equal to or less than the set
value.
