Embraer EMB145 - Page 1634

AIRPLANE
OPERATIONS
MANUAL
CREW
AWARENESS
REVISION 38
2-04-30
Page
13
Code
01
AOM-145/1114
EM145AOM042037B.DGN
1500 ft
143 ft LOSS
5 ft LOSS
30 ft
ALERT/WARNING AREA
0 40 80 120 160 200 240
280
0
200
400
600
800
1000
1200
1400
1600
1800
2000
2200
2400
2600
STATIC ALERT/WARNING ENVELOPE
MINIMUM TERRAIN CLEARANCE−ft
ALTITUDE LOSS−ft
DON’T SINK
POSITIVE RATE OF CLIMB
ALTITUDE
RESET
MODE 3 ALTITUDE LOSS AFTER TAKEOFF
GPWS/EGPWS MODE 3 SCHEMATIC
