1.3 DOTS
1000 ft
2.98 DOTS
30 ft
3.68 DOTS
SOFT ALERT AREA
GLIDE SLOPE
1000 ft
GLIDE SLOPE DEVIATION−DOTS FLY UP
300 ft
MINIMUM TERRAIN CLEARANCE−ft
2 DOTS
HARD ALERT AREA
MODE 5 EXCESSIVE GLIDE SLOPE DEVIATION
GPWS/EGPWS MODE 5 SCHEMATIC
