CONTROLS AND INDICATORS
STEEP APPROACH PUSHBUTTON
LIGHT
INDICATION
MODE DESCRIPTION
STEEP
Illuminates in white color when the airplane is
in the air and the flaps are in 45°. This means
that the Steep Approach mode is available.
GREEN LIGHT
Illuminates when the button is pressed with the
STEEP light illuminated. This means that the
Steep Approach mode is engaged.
With the STEEP light illuminated, if the green
light does not illuminates when the pushbutton
is pressed, means that the Steep Approach is
not engaged; in this case, do not perform
Steep Approach operations.
AMBER LIGHT
The Steep Approach mode is failed. Do not
perform Steep Approach operations. In this
situation, the Steep Approach mode is not
engaged and the airplane must land in an
airport that not requires steep approach
operation.
