− ROLL ANGLE
− PITCH ANGLE
ACCELERATION
− MAGNETIC HEADING
− NORMAL AND LONGITUDINAL
− TRUE AIRSPEED
− STATIC AIR TEMPERATURE
− COMPUTED AIRSPEED
− BARO ALTITUDE RATE
− UNCORRECTED BARO ALTITUDE
SPS:
− AOA
− FLAP POSITION
RADIO ALTITUDE
PFD 1:
− WS CAUTION
− WS WARNING
IC−600 1
EICAS:
− WS INOP
GO
AROUND
BUTTON
PFD 2:
− WS CAUTION
− WS WARNING
IC−600 2
AWU
WINDSHEAR
CARD
− CORRECTED BARO ALTITUDE
ADC:
− INERTIAL VERTICAL SPEED
− INERTIAL ALTITUDE
− LATITUDE AND LONGITUDE
EM145AOM042068B.DGN
IRS/AHRS:
GPWS/EGPWS
AND
WINDSHEAR
COMPUTER
WINDSHEAR DETECTION AND ESCAPE GUIDANCE
SYSTEM SCHEMATIC
NOTE: Inertial vertical speed, inertial altitude, latitude and longitude
are provided only for airplanes equipped with EGPWS.
