MULTI FUNCTION DISPLAY
1 - INNER RANGE RING
− Displayed around airplane symbol to indicate a 2 NM range.
− Removed if outer range indicates distance above 20 NM.
2 - OUTER RANGE RING
− May be selected up to 40 NM. Airplanes equipped with TCAS
software version 7.0 allow selection up to 100 NM.
3 - NO BEARING ADVISORIES INDICATION
− Indicates data related to a detected intruder, whose bearing
cannot be determined.
− Up to two lines may be displayed indicating the kind of advisory,
its distance, relative altitude and whether it is climbing or
descending in excess of 500 ft/min.
− Colors:
− No bearings RAs: red.
− No bearings TAs: amber.
4 - PROXIMATE TRAFFIC INDICATION
− Indicated by a solid cyan diamond.
− Represents any airplane within 6.5 NM horizontally and 1200 ft
vertically, but whose path is not predicted to penetrate the
Collision Area.
5 - INTRUDER’S VERTICAL MOVEMENT
− Indicated by an arrow next to the symbol that indicates if the
intruder is climbing or descending in excess of 500 ft.
− Color: Same as of the associated symbol.
