PRIMARY FLIGHT DISPLAY
For further information on Vertical Speed Indicator, refer to Section
2-17 – Flight Instruments.
VSI
− Indicates the recommended vertical speed to avoid a possible
conflict.
− Green range - displayed along the scale, indicates the range of
vertical speeds to be attained to avoid a conflict situation.
− Red range - displayed along the scale, indicates the range of
vertical speeds prohibited for the current situation.
− Green range may be displayed together with the red range or
split in two parts, depending on situation.
− Red range may be displayed alone, together with the green
range, or split in two parts, depending on the situation.
PRIMARY FLIGHT DISPLAY
