FUEL
AIRPLANE
OPERATIONS
MANUAL
2-08-05
Page
6
Code
01
REVISION 39
AOM-145/1114
FUEL
ENG 1 ENG 2APU
OFF
LOW LOW
12
XFEED
PUMP SEL
1A 1C 2A 2C
2B1B
ON
OFF
PUMP PWR
TANK 1 TANK 2
ON
OFF
FIRE
HANDLE
FIRE
HANDLE
TEMPERATURE
SENSOR
LOW PRESSURE
SWITCH
FPMU
ENGINE 1 ENGINE 2
TO APU
DIRECT MEASURING STICK
GRAVITY FILLER CAP
EJECTOR PUMP
DRAIN VALVE
DUMP VALVE
FLOAT VALVE
FLAP VALVE
LOW LEVEL SENSOR
ELECTRICAL PUMP
CHECK VALVE
SHUTOFF VALVE
MOTIVE FLOW
LEGENDS
CHECK/RELIEF VALVE
NACA AIR INLET
FPMU
FLAME ARRESTOR
LOW LEVEL
SENSOR
COLLECTOR
BOX
STUB
TANK
(*) APPLICABLE TO AIRPLANES WITH
HIGH LEVEL EXCEEDING INDICATION
(*)
H
HIGH LEVEL SWITCH
H
SURGE
BOX
DISCHARGE LINE
LOW PRESSURE SWITCH
EM145AOM082002A.DGN
FUEL SYSTEM SCHEMATIC
(AIRPLANES WITH STUB TANK)
