Embraer EMB145 - Page 1844

AIRPLANE
OPERATIONS
MANUAL
FUEL
REVISION 38
2-08-10
Page
3
Code
01
AOM-145/1114
OPEN
CLOSED
LH TANK
CLSD
STOP
RFL
RH TANK
CLSD
STOP
RFL
REFUELING
THE TWO "CLSD" WHITE
LIGHTS MUST BE ON
BEFORE OPENING
THE REFUEL SWITCH
REMOVE REFUELING PRESSURE
IF ANY RED LIGHT COMES ON
CALL MAINTENANCE
EM145AOM082007B.DGN
GRAVITY FILLER CAP
DRAIN VALVE
DUMP VALVE
FLOAT VALVE
FLAP VALVE
PILOT VALVE
VENT VALVE
PRESSURE SWITCH
REFUELING ADAPTER
REFUELING LINE
PILOT LINE
ELECTRIC SIGNAL
LEGENDS
CHECK/RELIEF VALVE
DECRT
TK SEL
TEST
INCR
REFUELING
DEFUELING
POWER SELECTION
NORMAL BATTERY
OPEN
CLOSED
OPEN
CLOSED
LH TANK RH TANK
CLOSED CLOSED OPEN
FUEL QTY REMAINING
SELECTED
NACA AIR INLET
FLAME ARRESTOR
H
HIGH LEVEL SWITCH
(*)
H
(*) APPLICABLE TO AIRPLANES WITH
HIGH LEVEL EXCEEDING INDICATION
OR
PRESSURE REFUELING/DEFUELING SYSTEM SCHEMATIC
