FUEL MEASURING STICK
Two measuring sticks under each wing permit to check the fuel
quantity in the tanks. Each measuring stick provides visual indication of
the total fuel quantity of the associated wing tank.
Information about using the Fuel Measuring Stick can be found in the
Ground Servicing Section (1-12-25).
NOTE: The EMB-145LR/LU, EMB-135LR, ERJ-140 and EMB-145XR
models have two additional measuring sticks, one for each
wing stub tank.
The table below provides minimum and maximum stick values:
STICK POSITION
AIRPLANES WITHOUT
WING STUB TANK
AIRPLANES WITH
WING STUB TANK
LITERS US GAL LITERS US GAL
Wing Stub Min
-- -- 7 2
Tank
Max -- -- 783 207
Internal Min
448 118 781 206
Point
Max
1553 410 2168 573
External Min
1503 397 2163 571
Point
Max
2131 563 2791 737
