AIRPLANE
OPERATIONS
MANUAL
POWERPLANT
REVISION 39
2-10-60
Page
1
Code
01
AOM-145/1114
CONTROLS AND INDICATORS
CONTROL PEDESTAL
1 - GUST LOCK LEVER
Limits thrust lever movement and locks the elevator control
surfaces when set in LOCKED position.
Refer to Section 2-13 − Flight Controls.
2 - THRUST LEVER
MAX - Provides maximum takeoff thrust.
THRUST SET - Provides N1TARGET thrust setting.
IDLE - Provides ground and flight idle thrust settings.
MAX REV - Provides maximum reverse thrust.
NOTE: Protection against inadvertent thrust reverser command in
flight is provided through the mechanical idle stop and the
electrical flight idle stop.
3 - FRICTION LOCK
Rotated clockwise, thrust lever movement becomes progressively
more resistant, so that thrust levers will not slip.
4 - THRUST RATING MODE buttons
T/O - Selects maximum takeoff thrust-rating mode.
CON - Selects maximum continuous thrust-rating mode.
CLB - Selects maximum climb thrust-rating mode.
CRZ - Selects maximum cruise thrust-rating mode.
