EICAS INDICATIONS
1 - LANDING GEAR POSITION
− Position is indicated by three boxes, one for each gear.
− Landing gear down and locked is indicated by a green DN label
inside a green box.
− Landing gear in transit is indicated when the box is cross-
hatched in amber and black.
− Landing gear up and locked is indicated by a white UP label
inside a white box.
− Landing gear lever disagreement (landing gear is not in the
selected position after 20 seconds) is indicated by a box cross-
hatched in red and black or by a red label (UP or DN) inside a
red box.
− Indication of landing gear downlocked is also presented on the
RMU through the green LG DOWN LOCKED legend.
