MFD INDICATIONS
1 - BRAKE TEMPERATURE INDICATION
− Temperature is indicated by two vertical bars (one for each
main landing gear) and four pointers (one for each brake).
− The scale ranges from 0 to 500°C.
− The scale and pointer are green when temperature is below
200°C, and amber when equal or greater than 200°C.
− The temperature indication pointer is removed from the display
in case of loss of temperature sensor signal.
NOTE: For EMB-145 airplanes equipped with LR brakes, the scale
and pointer are green when temperature is below 250°C, and
amber when equal or greater than 250°C.
BRAKES
TEMPS
OB OBIB IB
MFD
1
EM145AOM122011A.DGN
BRAKE TEMPERATURE INDICATION
