Embraer EMB145 - Page 1990

AIRPLANE
OPERATIONS
MANUAL
LANDING GEAR AND
BRAKES
REVISION 40
2-12-15
Page
9
Code
01
AOM-145/1114
EMB-135 MINIMUM TURNING RADII
EM145AOM122016.DGN
R1
R6
R3
R4
R2
R5
76°
3.10 m
60 ft 10 in
18,54 m
(RUN WAY MINIMUM WIDTH)
NOSE
R1
NOSE
GEAR
R2
OUTBOARD
GEAR
R3
INBOARD
GEAR
R4
RIGHT
WINGTIP
R5
RIGHT
TAILTIP
R6
76°
STEERING
STEEL
14.94 m
49 ft 0 in
13.05 m 5.49 m
18 ft 0 in
0.72 m
2 ft 4 in
13.27 m
43 ft 7 in
13.34 m
42 ft 10 in
43 ft 9 in
11 ft 10 in
