Embraer EMB145 - Page 1992

AIRPLANE
OPERATIONS
MANUAL
LANDING GEAR AND
BRAKES
REVISION 40
2-12-15
Page
11
Code
01
AOM-145/1114
EMB-140 MINIMUM TURNING RADII
EM145AOM122021A.DGN
R3
R5
R
4
R1
13,94 m
5,45 m
45ft 9 in
R
17 ft 11 in
R
65ft 8in
20,000 m
R
2
R6
13.53
(44ft 4in)
76°
(RUNWAY
MINIMUM WIDTH)
NOSE
R1
NOSE
GEAR
R2
OUTBOARD
GEAR
R3
INBOARD
GEAR
R4
RIGHT
WINGTIP
R5
RIGHT
TAILTIP
R6
76°
STEERING
STEEL
16.05 m
52 ft 8 in
14.16 m 5.74 m
0.98 m
3 ft 3 in
13.53 m
44 ft 5 in
14.40 m
47 ft 3 in
46 ft 6 in 18 ft 10 in
