FLIGHT CONTROLS
AIRPLANE
OPERATIONS
MANUAL
2-13-10
Page
18
Code
01
REVISION 38
AOM-145/1114
If the airplane is on the ground, any thrust lever angle is above
60° and pitch trim is outside the green band, the digits, box, and
pointer turn red, the aural warning TAKEOFF TRIM sounds and
the EICAS warning message NO TAKEOFF CONFIG is
displayed.
8
UP
PITCHROLL
YAW
SPLRS
FLAPS
O
CLD
EICAS
EM145AOM132041A.DGN
1
EICAS INDICATIONS
To Next Page
