FLIGHT CONTROLS
AIRPLANE
OPERATIONS
MANUAL
2-13-30
Page
4
Code
01
REVISION 32
EICAS MESSAGES
TYPE MESSAGE MEANING
CAUTION FLAP FAIL
Both flap channels are
inoperative.
ADVISORY FLAP LOW SPEED
One flap channel is
inoperative.
FLAP AURAL WARNING (TAKEOFF FLAPS)
If the airplane is on the ground, any thrust lever angle is above 60° and
the flaps are not in the certified takeoff position, the digits, box, and
pointer turn red, and the aural warning TAKEOFF FLAPS sounds. In
addition, only for flaps position of 0° and 45°, the EICAS warning
message NO TAKEOFF CONFIG is displayed.
CONTROLS AND INDICATORS
CONTROL PEDESTAL AFT PANEL
1 - FLAP SELECTOR LEVER
− Moved to the detent positions, selects each discrete flap position.
− To move the lever it is necessary to pull it up.
− Intermediate positions are not enabled.
