PNEUMATICS
AIR CONDITIONING
AND PRESSURIZATION
AIRPLANE
OPERATIONS
MANUAL
2-14-10
Page
18
Code
01
REVISION 38
AOM-145/1114
ATTENDANT’S CONTROL PANEL
1 - ON INDICATOR LIGHT (GREEN)
− Illuminates to indicate that the passenger cabin temperature
control is transferred to the attendant’s panel.
2 - PASSENGER CABIN TEMPERATURE CONTROL (KNOB OR
SLIDING CONTROL)
− Actuates on the passenger cabin temperature controller (right
ECU) in the automatic mode, provided the Passenger Cabin
Temperature and Mode Selector is set to the ATTD position.
− The attendant may set the passenger cabin to between 18°C
(65°F) and 29°C (85°F).
EM145AOM142005A.DGN
1
CABIN TEMP CONTROL
COLD HOT
ON
ATTENDANT’S
CONTROL
PANEL
CABIN TEMP CONTROL
COLD HOT
2
OR
ON
ATTENDANT’S CONTROL PANEL
To Next Page
