PNEUMATICS
AIR CONDITIONING
AND PRESSURIZATION
AIRPLANE
O
PERATIONS
MANUAL
2-14-15
Page
12
Code
02
REVISION 41
Copyright © by Embraer. Refer to cover page for details.
AOM
-
145/1114
MFD
1 - HIGH ALT STATUS INDICATION
− Displays HIGH ALT activation status.
− Boxed: HIGH ALT mode activated.
− Unboxed: HIGH ALT mode deactivated.
2 - HIGH ALT BEZEL BUTTON
− Provides HIGH ALT activation when pressed.
