WINDSHIELD DIFFERENTIATION
SIERRACIN WINDSHIELD
Sierracin windshields can be easily identified by their green colored tint
and by the positions of the bus bars to which the heater filaments are
attached, in the vertical direction, as shown below:
HEATING
CONDUCTIVE
ELEMENTS
BUS BAR
BUS BAR
EM145AOM942004A.DGN
SIERRACIN WINDSHIELD SCHEMATIC
