3 - HORIZONTAL STABILIZER ANTI-ICING BUTTON
− Turns off (released) or permits (pressed) the automatic activation of
the horizontal stabilizer anti-icing subsystem.
− A striped bar illuminates inside the button to indicate that it is
released.
− An OPEN inscription illuminates inside the button to indicate that the
horizontal stabilizer anti-icing valve is open.
4 - SENSOR HEATING BUTTONS
− The left button controls Pitot tube 1, AOA 1 vane, TAT 1 probe, ADC
Static Ports 1 and 3, and pressurization static port 1.
− The central button controls Pitot/Static tube 3 and pressurization static
port 2.
− The right button controls the Pitot tube 2, AOA 2 vane, TAT 2 probe
and ADC static ports 2 and 4.
− When pressed, the associated sensor heating system operates in
the automatic mode according to its functional logic. When released,
the associated sensor heating system is turned off.
− A striped bar illuminates inside the button to indicate that it is
released.
5 - ICE DETECTION TEST KNOB
Permits the half-wing, horizontal stabilizer and engine air inlet anti-icing
subsystems to operate for test purposes, by simulating an icing
condition on ice detectors 1 and 2. The adequate system operation is
confirmed by the illumination of the OPEN inscriptions in the anti-icing
buttons, which indicate the current valve position.
NOTE: The ICE CONDITION, ICE DET 1 (2) FAIL and BLD 1 (2) LOW
TEMP messages are displayed during test. The CROSS BLD
OPEN message is also presented for airplanes Pre-Mod. SB
145-36-0028.
