NAVIGATION/COMMUNICATION MEMORY PAGES
The Memory Page presents two similar displays called First Memory
Page and Second Memory Page. The First Memory Page shows
memory locations 1 through 6 and the Second Memory Page shows
memory location 7 through 12. Both the COM and NAV Memory Pages
are functionally identical.
HF MEMORY PAGE (only for KHF-1050)
The HF Memory Page manages the 12-channel non-volatile memory
frequencies and their transmission/reception mode, mode of operation
and squelch level .
HF CONTROL PAGE (only for KHF-1050)
The HF Control Page allows the pilot to select and adjust the active
and preset frequency, transmission/reception mode, mode of
operation, squelch level and Transmission (TX) power.
ATC/TCAS CONTROL PAGE
The ATC/TCAS Control Page allows the pilot to select various TCAS
operational features:
• Intruder Altitude
− REL: Target’s altitude displayed relative to one’s own airplane
(default).
− FL: Target’s altitude displayed as flight level (reverts to REL
after 20 sec).
• TA Display
− AUTO: Traffic targets displayed only when TA or RA target
conditions exist.
− MANUAL: All traffic targets displayed within the viewing
airspace.
• Flight ID
Allows Mode S coding to reflect the current flight’s call sign.
• Flight Level 1/2
Display of the transponder’s encoded altitude and the air data
source for that altitude.
NAVIGATION BACKUP PAGE
The NAVIGATION Backup Page consists of a backup navigation
display that presents HSI, MB, DME, NAV (VOR) and ADF information.
