AIRPLANE
OPERATIONS
MANUAL
NAVIGATION AND
COMMUNICATION
MARCH 30, 2001
2-18-40
Page
9
Code
01
4 - TO/FROM POINTER
− Color: White.
− Displayed towards the nose or the tail of the airplane to indicate,
respectively, "TO" or "FROM" the navigation aid.
5 - DME FIELD
− Displays Ground Speed, Time-to-go, and Elapsed Time.
− GROUND SPEED DISPLAY
− Color: Digits: green.
GSPD label: white.
− Range: 0 to 550 KIAS.
− Resolution: 1 KIAS.
− TIME TO GO DISPLAY
− Color: Digits: the same of the NAV source color.
TTG label: white.
− Range: 0 to 399 min.
− Resolution: 1 minute.
− ELAPSED TIME
− Color:
− Digits: green.
ET label: green.
− Range: 00:00 to 09:59 h.
− Resolution: Displayed in the format minutes: seconds (for
less than one hour), and hours (minutes for more than one
hour).
6 - COURSE DEVIATION SCALE
− Color: White.
7 - COURSE DEVIATION BAR
− Color:
− Green: when the source is the on-side VOR.
− Yellow: when the source is the cross-side VOR.
− Indicates against the course deviation scale, the difference
between the selected course and the VOR bearing.
