7 - TO WAYPOINT SYMBOL
− Color:
− Magenta: when the source is the on-side FMS.
− Yellow: when the source is the cross-side FMS.
− In the sequence established, the TO Waypoint is the next one
from the current airplane position.
8 - LATERAL DEVIATION DISPLAY
− Color: White.
− Right after the values there is a letter which may be L or R
standing for Left and Right respectively.
9 - WIND VECTOR DISPLAY
− Color:
− Magenta: when the source is the on-side FMS.
− Yellow: when the source is the cross-side FMS.
− A single vector shows the direction of the wind relative to the
airplane symbol. The digits indicate the wind intensity in knots.
10 - DESIGNATOR SYMBOL
− Color:
− Same color of the Waypoint: If the Designator is co-located
with a connected Waypoint.
− Cyan: If it is not connected.
− The Designator symbol is displayed as an unfilled rectangle
applied in two distinct methods: co-located with a Waypoint or
positioned with the joystick.
− Designator will not be displayed if it represents the current
position.
11 - TO WAYPOINT DATA ANNUNCIATIONS
− It is composed of the annunciators and presented as follows:
− Identification.
− Distance in nautical miles (NM).
− Time to the TO Waypoint in minutes (MIN).voyeur
− Color:
− For single FMS configuration the identification is magenta.
The distance and the time are white.
− For dual FMS configuration the identification, distance and
time are magenta, when the source is the on-side FMS, or
yellow, when the source is the cross-side FMS
