− For airplanes equipped with Dual Radar Controller
Configuration, the system behavior can be summarized as
follows:
WX
Controller #1
(LH side)
WX
Controller #2
(RH side)
MFD #1
Indication
MFD #2
Indication
#1
STDBY OFF
#2
STDBY WX
#3
WX OFF
#4
WX STDBY
Terrain map image and
ARC Range setting work
independently through
MFD Bezel #1 and #2
#5
OFF WX
#6
OFF STDBY
Terrain map
image is
copied from
MFD #2,
disregarding
local ARC
Range
setting
Terrain
map
matches
local ARC
Range
setting
NOTE: The mentioned characteristic is only valid for the Terrain Map
image and does not affect the EGPWS functions.
