AIRPLANE
OPERATIONS
MANUAL
NORMAL PROCEDURES
REVISION 36
1-02-95
Page
15
Code
05
AOM-145/1114
R
P
GLIDE SLOPE PATH
GLIDE SLOPE
ANGLE
P − HEIGHT OF THE PILOT’S EYE ABOVE THE WHEELS R − HEIGHT OF GLIDE RECEIVER ANTENNA ABOVE THE WHEELS
AIRPLANE
ATTITUDE
(DEGREES)
P
(FEET)
R
(FEET)
23°0’
14°4’
PILOT EYE POSITION
GROUND
3,0
4,4
14,6
11,0
4,9 14,9 11,42,5
GLIDE SLOPE
ANGLE
(DEGREES)
HORIZONTAL REFERENCE
EMB−145
CAT II OR AIII MODE APPROACH GEOMETRY AT
DECISION HEIGHT
JAA
EM145AOM021009A.DGN
FLAPS 22°
