PERFORMANCE
EMB-145 LB
AIRPLANE
OPERATION
MANUAL
1-04-20
Page
24
Code
02
REVISION 40
AOM-145/1114
EMB-145 TAKEOFF ANALYSIS, ALLISON AE3007A1 ENGINES, FAA CERTIFICATION
---------------------------------------------------------------------------------------------------
Airport: AIRPORT NAME ICAO: ABCD Runway: 04 Level Off Height: 400 ft FLAP 9
Elevation: 5000 ft
TORA: 2000 m
Clearway: 0 m
Stopway: 0 m
Slope: .6 %
Alignment allowance: 21 m
--------------------------------------------------------------------------------------------------
Thrust: T/O-1
Anti Ice: OFF
DRY RUNWAY
--------------------------------------------------------------------------------------------------
LIMIT WEIGHTS (Lb) as function of Temperature and Wind:
--------------------------------------------------------------------------------------------------
Temp(C)/N1(%) -10Kt 0Kt 10Kt 20Kt
--------------------------------------------------------------------------------------------------
-10 / 88.0 40280/ R 43244/ R 44186/ R 45030/ R
-8 / 88.4 40166/ R 43119/ R 44072/ R 44913/ R
-6 / 88.7 40053/ R 42997/ R 43943/ R 44798/ R
-4 / 89.0 39941/ R 42875/ R 43815/ R 44684/ R
-2 / 89.4 39830/ R 42754/ R 43689/ R 44572/ R
0 / 89.8 39720/ R 42635/ R 43563/ R 44460/ R
2 / 90.1 39598/ R 42512/ R 43434/ R 44346/ R
4 / 90.4 39474/ R 42391/ R 43307/ R 44234/ R
6 / 90.7 39349/ R 42269/ R 43179/ R 44121/ R
8 / 91.0 39226/ R 42148/ R 43052/ R 43993/ R
10 / 91.4 39104/ R 42027/ R 42925/ R 43860/ R
12 / 91.7 38987/ R 41912/ R 42804/ R 43733/ R
14 / 92.0 38873/ R 41792/ R 42684/ R 43607/ R
16 / 92.3 38756/ R 41667/ R 42563/ R 43479/ R
18 / 92.6 38641/ R 41542/ R 42442/ R 43352/ R
20 / 93.0 38527/ R 41419/ R 42321/ R 43226/ R
22 / 93.3 38414/ R 41295/ R 42201/ R 43100/ R
24 / 93.6 37783/ R 40595/ R 41496/ R 42391/ R
--------------------------------------------------------------------------------------------------
Limitation codes: 1,2,... - Obstacle No.; L = Level off; R - Runway; S - Structural; B - Brake Energy; W - WAT
V1/VR/V2 (Kt) vs. Weight and Temperature:
Temp/Weight 48500 46000 43500 41000 38500 36000 33500
--------------------------------------------------------------------------------------------------
-10 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
-6 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
-2 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
2 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
6 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
10 134/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
14 135/134/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
18 135/135/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
22 135/135/144 130/130/140 126/126/136 121/121/132 115/116/128 109/111/124 103/105/120
26 135/135/144 131/131/140 126/127/136 122/122/132 116/117/128 110/112/124 104/106/120
EXAMPLE 2
Wind (in knots)
Level off altitude and height (ft)
Temperature (in degrees Celsius)
and N1
(
in
p
ercenta
g
e
)
Weigh
t
in pounds and limitation code
Temperature (in degrees Celsius)
V
1
/
V
R
/
V
2
in knots
