1
1. Rear EMI shield
5. Insert and lock drives into the back bays until they are full.
1
2
3
1. Rear EMI shield 2. Locking handle 3. Drive bay
6. Replace the rear EMI shield.
Installation Guide
8 NL400 Installation Guide
