High Resistance Measurements
NOTE: An external DC power source variable up to 250V; a 270K,
5% resistor; and a 180K, 10% resistor are required to
make high resistance measurements.
1. Set up the Model 565 (555) and the external components and power supply as shown in figure 3.
