Chlorine Dioxide Generator LOTUS D
4.5.4 Installation example D
• Batch tank filling with water supply module
• Operation mode: “Batch”
11 Flushing unit with vacuum relieve valve 35 Batch or storage tank
12 Acid tank in safety tub 36 Back pressure valve
14 Chlorite tank in safety tub 50 Module “Water Supply”
12 14
35
50
11
36
LEV
LEV
LEV
LEV
Fig. 4.4
