LOCATION OF CONTROLS AND INDICATORS
Top Panel
1. Alarm 1 setting button.
2. Alarm Mode button.
(weekdays/weekends/everyday alarm)
3. Time Zone button.
4. Time setting button.
5. Date setting button.
6. Down button.
7. Up button.
8. Alarm 2 setting button.
9. Sleep Timer button.
10. Radio On/Off button.
11. Snooze (Sleep Off) button.
Left Side (Back)
12. Alarm 1 selector switch.
(Radio/Buzzer/Off)
13. Alarm 2 selector switch.
(Radio/Buzzer/Off)
14. Display Dimmer switch (Hi/Low)
Right Side
15. Volume control.
16. Band switch (AM/FM).
17. Tuning control.
Front Panel
18. Alarm 1 ‘On’ indicator.
19. AM indicator.
20. Time display.
21. Alarm 2 ‘On’ indicator.
22. Month/Date display.
23. Batt. Low Indicator.
24. Day indicators.
25. Lighted Dial Pointer.
Back Panel
26. Back up battery compartment.
27. AC power cord.
9
1234567
8
27
26
10
11
1 2 3 8
1 2 1 2
18 19 20 21 22 23
13
14
15
16
17
24
25
