Emerson 781S - Intended Use; System Architecture

2 Intended use
2.1 System architecture
The smart antenna must be used in conjunction with a network manager or
network gateway. The smart antenna then functions as a translator between
the wired network and a wireless field network.
Figure 2-1: Example System Architecture
