Emerson DIXELL XR60T User Manual

1592040000 XR20-30-60-70T EN v1.5 2021.06.22 XR20-30-60-70T 29/41
ALr
AH2
Second temperature alarm differential
4.0
Pr2
°F
[0.1°C to 25.0°C]
[0.1°F to 45.0°F]
ALr
Ad2
Second temperature alarm delay
0
Pr2
min
0 to 255 min
ALr
dA2
Second temperature alarm delay at start-
up
00:00
Pr2
hh:mm
0.0 to 24h00min
ALr
bLL
Compressor OFF due to second low
temperature alarm
no
Pr2
n(0); Y(1)
ALr
AC2
Compressor OFF due to second high
temperature alarm
n
Pr2
n(0); Y(1); MAn(2)
ALr
SAF
Differential for anti-freezing control
-2.0
Pr2
°F
[-12.0°C to 12.0°C]
[-21.6°F to 21.6°F]
ALr
tbA
Alarm relay deactivation
no
Pr2
n(0); Y(1)
oUt
oA2
Relay output oA2 configuration
dEF
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10); CP2(11);
dF2(12); HEt(13); inv(14)
oUt
oA3
Relay output oA3 configuration
FAn
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10); CP2(11);
dF2(12); HEt (13); inv(14)
oUt
oA4
Relay output oA4 configuration
LiG
Pr2
nu(0); CP1(1); dEF(2); FAn(3);
ALr(4); LiG(5); AUS(6); db(7);
onF(8); HES(9); Cnd(10); CP2(11);
dF2(12); HEt (13); inv(14)
oUt
AOP
Alarm relay polarity
CL
Pr2
oP(0); CL(1)
inP
ibt
Base times for digital inputs
Sec
Pr1
SEC(0); Min(1)
inP
i1P
Digital input 1 polarity
CL
Pr1
oP(0); CL(1)
inP
i1F
Digital input 1 configuration
dor
Pr1
nu(0); dor(1); dEF(2); AUS(3);
ES(4); EAL(5); bAL(6); PAL (7);
FAn(8); HdF(9); onF(10); LiG(11);
CC(12); EMt(13)
inP
did
Digital input 1 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
inP
i2P
Digital input 2 polarity
CL
Pr1
OP(0); CL(1)
inP
i2F
Digital input 2 configuration
EAL
Pr1
nu(0); dor(1); dEF(2); AUS(3);
ES(4); EAL(5); bAL(6); PAL (7);
FAn(8); HdF(9); onF(10); LiG(11);
CC(12); EMt(13)
inP
d2d
Digital input 2 alarm delay (base time
depends on par. ibt)
0
Pr1
sec
0 to 255 min/sec
inP
nPS
Number of external pressure switch alarms
before stopping the regulation
0
Pr2
0 to 15
inP
odC
Compressor and fan status after door
opening
no
Pr2
no(0); FAn(1); CPr(2); F-C(3)
inP
rrd
Regulation restart after door alarm
no
Pr2
n(0); Y(1)
inP
CLi
Light output activation from door input
no
Pr2
n(0); Y(1)
inP
LCi
Time with light output forced ON
(0=function disabled)
0
Pr2
0 to 255 min
inP
n01
Number of motion detections before
activating light output (valid if ixF=EMt)
0
Pr2
0 to 10
inP
t01
Time with light output forced ON after
motion detection
0
Pr2
0 to 255 min
ES
ErA
Energy saving algorithm
nu
Pr2
nu(0); bAS(1)
ES
HES
Energy saving mode temperature
differential
0
Pr1
°F
[-30°C to 30°C]
[-54°F to 54°F]
ES
LdE
Energy saving controls the lights (lights
OFF when energy saving mode is active)
no
Pr1
n(0); Y(1)
ES
StE
Period to switch from normal mode to
energy saving mode
00:00
Pr1
hh:mm
0 to 23h50min; nu
ES
EtS
Period to switch from energy saving mode
to normal mode
00:00
Pr1
hh:mm
0 to 23h50min; nu
