Emerson EWT19S2 Service Manual

5-5 L6118EA
10. V. Position Adjustment
Purpose:
To obtain correct vertical height of screen
image.
Symptom of misadjustment:
If V. Position is incor-
rect, vertical height of image on the screen may not be
properly displayed.
Note:
Use Service remote control unit
1. Operate the unit for at least 20 minutes.
2. Enter the Service mode. (See page 5-1)
3. Receive the Monoscope Pattern.
4. Press "9" button on the Service remote control unit
and select "V-P" mode. (Display change "V-S" and
"V-P" cyclically when "9" button is pressed.)
5. Press "CH o / p" buttons on the Service remote
control unit so that the top and bottom of the mono-
scope pattern becomes equal to each other.
6. Turn the power off and on again, using the main
power button on the TV unit.
11. H. Position Adjustment
Purpose:
To obtain correct horizontal position of
screen image.
Symptom of Misadjustment:
If H. Position is incor-
rect, horizontal position of image on the screen may
not be properly displayed.
Note:
Use Service remote control unit
1. Operate the unit for at least 20 minutes.
2. Enter the Service mode. (See page 5-1)
3. Receive the Monoscope Pattern.
4. Press "8" button on the Service remote control unit
and select " H-P " mode.
5. Press "CH o / p" buttons on the Service remote
control unit so that the monoscope pattern be-
comes 90±5% of display size and the circle is
round.
6. Turn the power off and on again, using the main
power button on the TV unit.
Test Point Adj. Point Mode Input
---
Screen Control
CH o / p
buttons
[ V-P ] Mode
RF
Mono
scope
Tape M. EQ. Spec.
--- Monoscope 90±5%
Test Point Adj. Point Mode Input
---
Screen Control
CH o / p
buttons [ H-P ]
Mode
RF
Mono
scope
Tape M. EQ. Spec.
--- Monoscope 90±5%
