Emerson EWT19S2 Service Manual

20020426 12-1 L6118CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTE:
Parts that are not assigned part numbers (----------) are
not available.
Ref. No. Description Part No.
A-1 FRONT CABINET L6118UU 0EM000672
A-2 REAR CABINET L1400UA 0EM000482
A-3 CONTROL PLATE L6118UU 0EM201635
A-4# RATING LABEL L6118UU ------------
B-1 TENSION SPRING B0080B0:EM40808 26WH006
B-2 CRT MOUNTING SCREW B0030U1:K42419 8A00083
B-3 PCB HOLDER L1400UA 0EM301429
B-4 SPEAKER HOLDER L1400UA 0EM406026
B-5# DEGAUSS HOLDER L9800UA 0EM404845
B-8 SPEAKER HOLDER L1400UA 0EM406098
B-11 CLOTH L9800UA:95X15XT:0.5 0EM405041
B-15 CLOTH(10X30XT1.0) L9814UQ 0EM405137
CLN551 CRT GND WIRE CRT GND WX1L7820-003
CLN801 WIRE ASSEMBLY SPEAKER WIRE(220MM) WX1L7950-001
CLN802 WIRE ASSEMBLY SPEAKER WIRE(180MM) WX1L1131-001
DG691# DEGAUSSING COIL AVDG014 or LLBH00ZWR003
# DEGAUSSING COIL F-003 LLBH00ZTM003
L-8 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
L-9 SCREW TAPPING M4X14 DBU14140
L-13 SCREW, P-TIGHT 3X12 BIND HEAD+ GBMP3120
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
SP802 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
PACKING
S-1 CARTON L6118UU 0EM407440
S-2 STYRFOAM B0TTOM ASSEMBLY L6100UA 0EM406813
S-3 STYRFOAM TOP ASSEMBLY L9814UQ 0EM405094
S-4 SET SHEET L1400UA:1000X1500 0EM406680
S-5 SERIAL NO. LABEL L6118UU 0EM407439
S-6 HOLD PAD L6100UA 0EM406812
ACCESSORIES
X-1 REMOCON UNIT 130/ERC001/N0158UD N0158UD
X-2 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI XB0M451HU003
X-3# OWNER'S MANUAL(E)/(S) L6118UU:ENGLISH/
SPANISH
0EMN01978
X-5 POLYETHYLENE BAG F8626B5 Z325350
X-9 RETURN STOP SHEET T4259UK 0EM406203A
Note:
1. V501 (CRT) HAS COUPLE OF SUBSTITUTIONAL PARTS AND EACH PARTS
ALSO HAS MATCHING COMBINATION WITH DY551.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
2. DY551 (DEFLECTION YOKE) HAS MATCHING COMBINATION WITH V501.
PLEASE SEE TABLE 1 FOR DETAILS OF MATCHING COMBINATION.
CRT TYPE A
DY551# DEFLECTION YOKE KDY3MDA84X or LLBY00ZMS013
# DEFLECTION YOKE LLBY00ZSY006 or LLBY00ZSY006
# DEFLECTION YOKE CDY-M2019F LLBY00ZQS004
V501# CRT A48JLL90X or TCRT190QS009
# CRT A48JLL90X(K) TCRT190QS019
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE B
DY551# DEFLECTION YOKE KDY3MCB20X or LLBY00ZMS016
# DEFLECTION YOKE 330P510A37 LLBY00ZTHA01
V501# CRT A48LGS30X TCRT190THA01
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE C
DY551# DEFLECTION YOKE DSE-1922FU(T) or LLBY00ZSM007
# DEFLECTION YOKE TMY0301F or LLBY00ZMS017
# DEFLECTION YOKE CDY-M2023F or LLBY00ZQS005
# DEFLECTION YOKE LLBY00ZSY007 LLBY00ZSY007
V501# CRT A48LRH93X(W) TCRT190P7002
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE D
DY551# DEFLECTION YOKE LLBY00ZSY008 LLBY00ZSY008
V501# CRT A48LVL095X TCRT190MS011
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE E
V501# CRT A48AKH13X01 K TCRT190CP043
CRT TYPE F
DY551# DEFLECTION YOKE KDY3MDD74X LLBY00ZMS024
V501# CRT A48AKH13X TCRT190CP044
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W or XV10000T4001
WEDGE DB25SR XV10000D9001
CRT TYPE G
DY551# DEFLECTION YOKE DSE-1922FU(T) or LLBY00ZSM007
# DEFLECTION YOKE TMY0301F or LLBY00ZMS017
# DEFLECTION YOKE CDY-M2023F or LLBY00ZQS005
# DEFLECTION YOKE LLBY00ZSY007 LLBY00ZSY007
V501# CRT A48LRH93X(W) TCRT190PTD01
Ref. No. Description Part No.
