8
1.) CD Door.
2.) Battery Compartment (Inside CD compartment).
3.) DC 4.5V Input Jack – Connect an AC adapter (not included) to this
jack to use 120V 60Hz AC house current.
4.) HOLD (On/Off) Switch – Slide to the right to lock the function of
the control buttons.
5.) EQ Button – Press repeatedly to select ROCK, SRR, POP, Flat EQs.
6.) Open “ ” Switch – Slide to the right to unlock and open the CD
door.
7.) VOLUME + / – Buttons – Raises or lowers the volume.
8.) Headphone Jack – Connect stereo headphones, included, to this
jack.
9.) MODE Button – To select the playback mode: Repeat 1/ALL, INTRO
or SHUF (Shuffle).
10.) PROG (Program) Button – To program the playback tracks.
11.) SKIP/SEARCH Forward Button.
12.) SKIP/SEARCH Reverse Button.
13.) STOP Button.
14.) PLAY/PAUSE Button.
15.) LCD Display – Shows Track number, Elapsed Time, Program, Repeat,
Shuffle, and Intro modes.
