Emerson LC320EM2F Service Manual

2011/12/05 14-3 A17F0EL.fm
C1301 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1302 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1303 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1304 ELECTROLYTIC CAP. 220µF/35V M CE1GMASDL221
C1305 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1311 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1500 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1501 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1502 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C1700 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
C1702 CAP CHIP 3216 B K 1µF/50V CA1J105TE142
C1703 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1704 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1705 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1706 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1707 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1708 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1709 ELECTROLYTIC CAP. 2200µF/35V M CE1GMZNDL222
C1710 CAP CHIP 3216 B K 1µF/50V CA1J105TE142
CONNECTORS
CN200 FFC CONNECTOR IMSA-9615S-11A-PP-A JC96J11ER007
CN600# VH CONNECTOR PRINT OSU B2P3S-
VH(LF)(SN)
J3VH030JG002
CN632 FMN CONNECTOR TOP 19P IMSA-9615S-19A-
PP-A
JC96J19ER007
CN1100# CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1101# CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1102# CONNECTOR/JACK 1747386-1 JB17J02AP002
DIODES
D200 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D201 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D202 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D205 DIODE ZENER 24BSC-T26 NDTC024BST26
D206 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D207 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D208 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D210 DIODE ZENER 6V2BSB-T26 NDTB6R2BST26
D211 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D212 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D221 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D222 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D600# DIODE GENERAL PURPOSE 1N5406-BU NDLZ1N5406BU
D601# DIODE GENERAL PURPOSE 1N5406-BU NDLZ1N5406BU
D602# DIODE GENERAL PURPOSE 1N5406-BU NDLZ1N5406BU
D603# DIODE GENERAL PURPOSE 1N5406-BU NDLZ1N5406BU
D604# DIODE ZENER 27BSB-T26 NDTB027BST26
D605 DIODE ZENER 4V3BSB-T26 NDTB4R3BST26
D607# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D609 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D610# DIODE ZENER 1ZB36BB NDWZ0001ZB36
D611 DIODE ZENER 1ZB220-YBB NDWZ01ZB220Y
D613 DIODE FAST RECOVERY FR155-B/P NDWZ0FR155BP
D631 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D632 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D633 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D634 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D635 DIODE ZENER 1ZB7.5BB NDWZ001ZB7R5
D637 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D638 DIODE ZENER 10BSB-T26 NDTB010BST26
D639 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D640 DIODE SCHOTTKY SMD SK2B-TR ND1Z00SK2BTR
D641 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D642 DIODE SK16-T/R ND1Z0000SK16
Ref. No. Description Part No.
D643 DIODE SK16-T/R ND1Z0000SK16
D644 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D645 DIODE ZENER 1ZB22BB NDWZ0001ZB22
D646 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D648 DIODE ZENER 1ZB30BB NDWZ0001ZB30
D649 DIODE SK16-T/R ND1Z0000SK16
D650 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D651 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D652 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D654 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D655 DIODE ZENER 3V3BSB-T26 NDTB3R3BST26
D656 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D657 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D658 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D660 DIODE FAST RECOVERY RS1GJTB ND1Z0RS1GJTB
D663 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1200 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1201 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1202 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1203 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1300 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D1301 DIODE ZENER 5V6BSB-T26 NDTB5R6BST26
D1500 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1501 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1502 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1503 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1504 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1505 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1506 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1507 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1508 SWITCHING DIODE DAN202U T106 QD1Z0DAN202U
D1700 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1701 DIODE ZENER 15BSB-T26 NDTB015BST26
D1702 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1703 DIODE ZENER 15BSB-T26 NDTB015BST26
D1704 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1705 DIODE ZENER 15BSB-T26 NDTB015BST26
D1706 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1707 DIODE ZENER 15BSB-T26 NDTB015BST26
ICS
IC200 IC TL3472CDR NSZBA0TTY115
IC202 IC(REGULATOR) PQ200WNA1ZPH QSZBA0TSH072
IC601# IC PHOTOCOUPLER TLP781F(D4-FUNBLL F) QPEL781FBLLF
IC1200 IC INVERTER CONTROL BD9244AFV/SSOP/
24PIN
QSCA0T0RM222
COILS
L600# COIL LINE FILTER ST0807ET28-009 10MH LLEG0Z0Y2029
L601# COIL LINE FILTER ST0807ET28-009 10MH LLEG0Z0Y2029
TRANSISTORS
Q200 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q201 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q202 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q203 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q204 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q206 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q207 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q208 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q210 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q211 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q212 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q213 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q214 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q221 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Ref. No. Description Part No.
