Emerson LC320EM2F Service Manual

2011/12/05 14-4 A17F0EL.fm
Q222 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q600# FET MOS TK10A50D QFWZTK10A50D
Q601# TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q631 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q632 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q633 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q634 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q635 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q636 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q1201 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1202 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1300 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1301 CHIP TRANSISTOR KTC3875S-Y-RTK/P NQ1YKTC3875S
Q1303 PNP TRANSISTOR SMD 2SA1576UBTLQ QQ1Q2SA1576U
Q1700# FET MOS SMD TK50P04M1(T6RSS-Q) QF1ZK50P04M1
Q1701# FET MOS SMD TK50P04M1(T6RSS-Q) QF1ZK50P04M1
Q1702# FET MOS SMD TK50P04M1(T6RSS-Q) QF1ZK50P04M1
Q1703# FET MOS SMD TK50P04M1(T6RSS-Q) QF1ZK50P04M1
RESISTORS
R200 RES CHIP 1608 1/10W J 100k Ω RRXA104HH013
R201 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
R203 RES CARBON FILM T 1/4W J 560 Ω RCX4561T1001
R205 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
R206 RES CHIP 1608 1/10W J 100k Ω RRXA104HH013
R207 RES CHIP 1608 1/10W J 1.0 Ω RRXA1R0HH013
R208 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R209 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R210 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R211 RES CARBON FILM T 1/4W J 10 Ω RCX4100T1001
R212 RES CHIP 1608 1/10W J 100k Ω RRXA104HH013
R213 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R215 RES CHIP 1608 1/10W J 12k Ω RRXA123HH013
R216 RES CHIP 1608 1/10W J 1.2k Ω RRXA122HH013
R217 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R218 RES CHIP 1608 1/10W J 15k Ω RRXA153HH013
R219 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
R222 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R224 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R225 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R226 RES CHIP 1608 1/10W F 330 Ω RTW3300HH008
R227 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R228 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R229 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R230 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R231 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R232 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R233 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R234 RES. CARBON FILM J 1/2W J 2.2 Ω RCX22R2T1003
R235 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R236 RES CHIP 1608 1/10W F 11.0k Ω RTW1102HH008
R237 RES CHIP 1608 1/10W F 750 Ω RTW7500HH008
R238 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R239 METAL OXIDE FILM RES. 1W J 8.2 Ω RN018R2ZU001
R240 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R241 RES CHIP 1608 1/10W J 6.8k Ω RRXA682HH013
R242 RES CHIP 1608 1/10W J 2.7k Ω RRXA272HH013
R243 RES CHIP 1608 1/10W F 240 Ω RTW2400HH008
R244 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R246 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R247 RES CHIP 1608 1/10W J 100k Ω RRXA104HH013
R248 RES CHIP 1608 1/10W J 56k Ω RRXA563HH013
R249 RES CHIP 1608 1/10W J 6.8k Ω RRXA682HH013
Ref. No. Description Part No.
R251 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R252 RES CHIP 1608 1/10W J 39k Ω RRXA393HH013
R253 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R254 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R255 RES CARBON FILM T 1/4W J 390 Ω RCX4391T1001
R256 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R257 RES CARBON FILM T 1/4W J 8.2k Ω RCX4822T1001
R258 RES CARBON FILM T 1/4W J 2.7k Ω RCX4272T1001
R260 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R261 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R262 RES CHIP 1608 1/10W J 12k Ω RRXA123HH013
R263 RES CARBON FILM T 1/4W J 470 Ω RCX4471T1001
R264 RES CHIP 1608 1/10W J 15k Ω RRXA153HH013
R265 RES CARBON FILM T 1/4W J 8.2k Ω RCX4822T1001
R266 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R267 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R268 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R269 RES CHIP 1608 1/10W J 12k Ω RRXA123HH013
R270 RES CHIP 1608 1/10W J 1.5k Ω RRXA152HH013
R600 RES CHIP 3216 1/4W J 220k Ω RRX4224HH034
R601# RES. CARBON FILM J 1/2W J 1.2M Ω RCX2125T1003
R602# CEMENT RESISTOR 5W J 2.2 Ω H 10MM RW052R2PAK10
R603 RES CHIP 3216 1/4W J 220k Ω RRX4224HH034
R604 RES CHIP 3216 1/4W J 220k Ω RRX4224HH034
R605 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R606 RES CARBON FILM T 1/4W J 180 Ω RCX4181T1001
R607 RES CARBON FILM T 1/4W J 1.2k Ω RCX4122T1001
R608# METAL OXIDE FILM RES. 2W J 0.18 Ω RN02R18ZU001
R609 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R610 RES CARBON FILM T 1/4W J 270 Ω RCX4271T1001
R611# CEMENT RESISTOR 5W J 2.2 Ω H 10MM RW052R2PAK10
R612 METAL OXIDE FILM RES. 1W J 68k Ω RN01683ZU001
R613 METAL OXIDE FILM RES. 1W J 68k Ω RN01683ZU001
R631 RES CHIP 1608 1/10W J 15k Ω RRXA153HH013
R632 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R633 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R634 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R635 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R636 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R637 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R638 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R641 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R642 RES CHIP 1608 1/10W F 43.0k Ω RTW4302HH008
R643 RES CHIP 1608 1/10W F 47.0k Ω RTW4702HH008
R644 RES CHIP 1608 1/10W J 18k Ω RRXA183HH013
R645 RES CHIP 1608 1/10W F 27.0k Ω RTW2702HH008
R647 RES CHIP 1608 1/10W F 27.0k Ω RTW2702HH008
R649 RES CARBON FILM T 1/4W J 3.9k Ω RCX4392T1001
R650 RES CHIP 1608 1/10W J 1.0 Ω RRXA1R0HH013
R651 RES CHIP 1608 1/10W F 820 Ω RTW8200HH008
R652 RES CHIP 1608 1/10W F 18.0k Ω RTW1802HH008
R654 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R655 RES CHIP 1608 1/10W J 47k Ω RRXA473HH013
R656 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R657 RES CARBON FILM T 1/4W J 15 Ω RCX4150T1001
R658 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R659 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R660 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
R662 RES CARBON FILM T 1/4W J 220 Ω RCX4221T1001
R663 RES CHIP 1608 1/10W J 39k Ω RRXA393HH013
R664 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1100 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1101 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
Ref. No. Description Part No.
