Emerson LC320EM2F Service Manual

2011/12/05 14-5 A17F0EL.fm
R1102 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1103 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1104 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1105 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1106 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1107 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1108 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1109 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1110 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1111 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1112 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1113 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1114 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1115 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1116 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1117 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1118 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1119 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1120 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1121 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1122 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1123 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1124 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1125 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1126 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1127 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1128 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1129 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1130 RES CARBON FILM T 1/4W G 470 Ω RCX4471T1002
R1131 RES CHIP 1608 1/10W F 100 Ω RTW1000HH008
R1132 RES CHIP 1608 1/10W F 13.0 Ω RTW13R0HH008
R1133 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1134 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1135 RES CHIP 1608 1/10W F 2.20k Ω RTW2201HH008
R1200 RES CHIP 1608 1/10W J 68k Ω RRXA683HH013
R1201 RES CHIP 1608 1/10W J 68k Ω RRXA683HH013
R1202 RES CHIP 1608 1/10W F 130k Ω RTW1303HH008
R1203 RES CHIP 1608 1/10W F 8.20k Ω RTW8201HH008
R1204 RES CHIP 1608 1/10W F 75.0k Ω RTW7502HH008
R1205 RES CHIP 1608 1/10W F 560k Ω RTW5603HH008
R1206 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1207 RES CHIP 1608 1/10W J 33k Ω RRXA333HH013
R1208 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R1209 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1212 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1213 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1214 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1215 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1216 RES CHIP 1608 1/10W J 100 Ω RRXA101HH013
R1221 RES CHIP 1608 1/10W J 1.0 Ω RRXA1R0HH013
R1222 RES CHIP 1608 1/10W J 10 Ω RRXA100HH013
R1223 RES CHIP 1608 1/10W J 10 Ω RRXA100HH013
R1229 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R1300 RES CHIP 1608 1/10W F 10.0k Ω RTW1002HH008
R1301 RES CHIP 1608 1/10W F 47.0k Ω RTW4702HH008
R1302 RES CHIP 1608 1/10W F 51.0k Ω RTW5102HH008
R1303 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1304 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1305 METAL OXIDE RES. 2W J 510 Ω RN02511ZU001
R1306 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1307 RES CHIP 1608 1/10W J 1.0k Ω RRXA102HH013
R1308 RES CHIP 1608 1/10W J 4.7k Ω RRXA472HH013
R1309 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
Ref. No. Description Part No.
R1310 RES CHIP 1608 1/10W J 22k Ω RRXA223HH013
R1500 RES CHIP 1608 1/10W F 1.00M Ω RTW1004HH008
R1501 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1502 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1503 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1504 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1505 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1506 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1507 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1508 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1509 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1510 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1511 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1512 RES CHIP 1608 1/10W F 100k Ω RTW1003HH008
R1513 RES CHIP 1608 1/10W F 1.00M Ω RTW1004HH008
R1514 RES CHIP 1608 1/10W F 39.0k Ω RTW3902HH008
R1515 RES CHIP 1608 1/10W F 27.0k Ω RTW2702HH008
R1516 RES CHIP 1608 1/10W F 6.80k Ω RTW6801HH008
R1700 RES CHIP 1608 1/10W J 100 Ω RRXA101HH013
R1701 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1702 RES CHIP 1608 1/10W J 100 Ω RRXA101HH013
R1703 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1704 METAL OXIDE FILM RES. 1W J 4.7 Ω RN014R7ZU001
R1705 RES CHIP 1608 1/10W J 100 Ω RRXA101HH013
R1706 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1707 RES CHIP 1608 1/10W J 100 Ω RRXA101HH013
R1708 RES CHIP 1608 1/10W J 10k Ω RRXA103HH013
R1709 METAL OXIDE FILM RES. 1W J 4.7 Ω RN014R7ZU001
MISCELLANEOUS
B41 HEAT SINK PNB ASSEMBLY A94F0UH 1EM428123
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
F601# FUSE STC4A125V U/CT PAGE20CW3402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
JS200 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS660 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
JS1200 WIRE COPPER 6111-06003-0120 XZ40C0SHG002
L17 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T600# TRANS POWER 11714 LTT3PC0KT069
When you replace one of the below Trans Inverters on this CBA, please
replace with the one that has same parts number.
Do not mix different parts number’s Trans Inverter.
T1100# TRANS INV HVT-325 LTZ3PZ0XB018
T1101# TRANS INV HVT-325 LTZ3PZ0XB018
T1102# TRANS INV HVT-325 LTZ3PZ0XB018
or
T1100# TRANS INV TZ.7617A.101 LTZ3PZDAR014
T1101# TRANS INV TZ.7617A.101 LTZ3PZDAR014
T1102# TRANS INV TZ.7617A.101 LTZ3PZDAR014
Ref. No. Description Part No.
