Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
32MF301B/F7 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL ASSEMBLY
Consists of the following:
A17FEMMA-001
DIGITAL MAIN CBA UNIT A17FEMMA-001-DM
FUNCTION CBA UNIT A17FEMMA-001-FN
IR SENSOR CBA UNIT A17FEMMA-001-IR
POWER SUPPLY CBA A17F7MPW-001
C602 CAP ELECTROLYTIC 390µF/200V CEB391DYG006
C603 Not used
C604 Not used
CN600# Not used
CN601# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
D205 DIODE ZENER 33BSB-T26 NDTB033BST26
D210 DIODE ZENER 5V1BSB-T26 NDTB5R1BST26
D661 DIODE FAST RECOVERY RS1GJTB ND1Z0RS1GJTB
D662 DIODE FAST RECOVERY RS1GJTB ND1Z0RS1GJTB
R203 RES CARBON FILM T 1/4W J 1.0k Ω RCX4102T1001
R208 Not used
R210 Not used
R213 Not used
R215 RES CHIP 1608 1/10W F 10.0k Ω RTW1002HH008
R216 RES CHIP 1608 1/10W F 1.50k Ω RTW1501HH008
R217 RES CHIP 1608 1/10W F 10.0k Ω RTW1002HH008
R218 RES CHIP 1608 1/10W F 10.0k Ω RTW1002HH008
R233 RES. CARBON FILM J 1/2W J 8.2 Ω RCX28R2T1003
R234 RES. CARBON FILM J 1/2W J 5.6 Ω RCX25R6T1003
R235 RES. CARBON FILM J 1/2W J 5.6 Ω RCX25R6T1003
R236 RES CHIP 1608 1/10W F 9.10k Ω RTW9101HH008
R237 RES CHIP 1608 1/10W 0 Ω RRXA000HH014
R255 RES CARBON FILM T 1/4W J 150 Ω RCX4151T1001
R257 RES CARBON FILM T 1/4W J 47k Ω RCX4473T1001
R258 RES CARBON FILM T 1/4W J 680 Ω RCX4681T1001
R263 RES CARBON FILM T 1/4W J 270 Ω RCX4271T1001
R268 RES CARBON FILM 1/4W J 39k Ω RCX4393FS002
R605 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R606 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R633 Not used
R634 Not used
R642 RES CHIP 1608 1/10W F 75.0k Ω RTW7502HH008
R660 Not used
R1101 Not used
R1110 Not used
R1113 Not used
R1122 Not used
R1125 Not used
R1134 Not used
R1214 Not used
R1229 Not used
FH601 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
FH602 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
JS200 Not used
JS1200 Not used
Ref. No. Description Part No.
