TYPE A
PARTS LIST [CLC320EM2F (Serial No.: DS1)]
Mechanical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Different parts from the original model
32MF301B/F7 (Serial No. : DS1)
Ref. No. Description Part No.
A1 FRONT CABINET A17FDUH 1EM227004
A12# RATING LABEL A17FWCH ----------
A15 Not used
A42 Not used
AC600# AC CORD W/O A GND WIRE UL/CSA/1730/NO/
BLACK
WAC1720LW006
B11 SPEAKER HOLDER A17F1UH 1EM126473
B27 Not used
B63 Not used
B64 Not used
B66 Not used
B67 Not used
B72 Not used
CL3101 WIRE ASSEMBLY 2PIN 2PIN/250MM/BLACK
RED
WX1A17F1T217
CL3102 WIRE ASSEMBLY 7PIN 7PIN/600MM/BLACK
RED
WX1A17F1T216
L42 SHOULDER SCREW A01Q0UF 1EM328277
LCD1 LCD MODULE 31.5INCH 31.5INCH UK32MXJ
SP3801 SPEAKER MAGNETIC S0412F28E DS08130XQ004
SP3802 SPEAKER MAGNETIC S0412F28E DS08130XQ004
S1 CARTON A17FWCH 1EM436899
X2# OWNERS MANUAL A17FWCH 1EMN28919
X3 REMOTE CONTROL NH001UD NH001UD
X6 QUICK START GUIDE A17F1UH 1EMN27480A
X7 REGISTRATION CARD (EMERSON) A17N1UH 1EMN27763
