Electrical Parts
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Different parts from the original model
32MF301B/F7 (Serial No. : DS1)
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL ASSEMBLY
Consists of the following
A17FDMMA-003
DIGITAL MAIN CBA UNIT A17FDMMA-003-DM
FUNCTION CBA UNIT A17FDMMA-003-FN
IR SENSOR CBA UNIT A17FDMMA-003-IR
POWER SUPPLY CBA A17FDMPW-001
C602 CAP ELECTROLYTIC 390µF/200V CEB391DYG006
C603 Not used
C604 Not used
CN600# Not used
CN601# CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
D611 Not used
D635 Not used
Q1700# FET MOS SMD TK40P04M1(T6RSS-Q) QF1ZK40P04M1
Q1701# FET MOS SMD TK40P04M1(T6RSS-Q) QF1ZK40P04M1
Q1702# FET MOS SMD TK40P04M1(T6RSS-Q) QF1ZK40P04M1
Q1703# FET MOS SMD TK40P04M1(T6RSS-Q) QF1ZK40P04M1
R208 Not used
R210 Not used
R213 Not used
R605 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R606 RES CARBON FILM T 1/4W J 120 Ω RCX4121T1001
R633 Not used
R634 Not used
R642 RES CHIP 1608 1/10W F 75.0k Ω RTW7502HH008
R660 Not used
R1101 Not used
R1110 Not used
R1113 Not used
R1122 Not used
R1125 Not used
R1134 Not used
R1214 Not used
R1229 Not used
FH601 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
FH602 FUSE HOLDER MSF-015-RS-SN (B110) XH001Z0LY001
JS200 Not used
JS1200 Not used
