Emerson LC320EM8 Service Manual

20070424 13-2 A71F3EL
C864 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C865 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C866 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C867 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C868 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C869 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C870 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C871 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C872 CHIP CERAMIC CAP. F Z 0.068µF/50V CHD1JZ30F683
C873 CHIP CERAMIC CAP.(1608) B K 5600pF/50V CHD1JK30B562
C875 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
C876 ELECTROLYTIC CAP. 4.7µF/25V M CE1EMASDL4R7
C877 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C878 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C880 CHIP CERAMIC CAP. (1608) B K 1µF/16V CHD1CK30B105
C1602 ALUMINUM ELECTROLYTIC CAP 1000µF/35V
M
CE1GMZNTM102
C1603 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
CONNECTORS
CN101B PH CONNECTOR TOP 8P B8B-PH-K-S
(LF)(SN)
J3PHC08JG029
CN301 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN302 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN601 WIRE ASSEMBLY 004 3PIN / 130MM / AWG18 WX1A71F0-004
CN801 CONNECTOR BASE 2P(EH) B 2B-EH-
A(LF)(SN)
J3EHC02JG010
CN802 CONNECTOR BASE 2P(EH) B 2B-EH-
A(LF)(SN)
J3EHC02JG010
DIODES
D602# ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D603 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D604# ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D605 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D606 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D607 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D608 DIODE TRANSIENT VOLTAGE SUPPRE
P6KE250ABE
NDLZP6KE250A
D609 DIODE FAST RECOVERY FR157 NDLZ000FR157
D611 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D612 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D631 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D632 SCHOTTKY BARRIER DIODE ERC81-004 QDPZERC81004
D633 RECTIFIER DIODE FR202-B/P NDQZ000FR202
D635 ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D636 RECTIFIER DIODE FR203-B/P NDQZ000FR203
D637 SCHOTTKY BARRIER DIODE ERC81-004 QDPZERC81004
D640 SCHOTTKY BARRIER DIODE ERC81-004 QDPZERC81004
D642 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D643 ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D644 DIODE 1ZC43(Q) QDLZ001ZC43Q
D646 ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D647 SCHOTTKY BARRIER DIODE ERC81-004 QDPZERC81004
D649 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D650 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D651 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D652 PCB JUMPER D0.6-P5.0 JW5.0T
D654 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D655 DIODE FR104-B NDLZ000FR104
D656 PCB JUMPER D0.6-P5.0 JW5.0T
D657 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D658 ZENER DIODE MTZJT-775.1B QDTB0MTZJ5R1
D659 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D660 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D661 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Description Part No.
D663 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D664 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D665 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D666 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D667 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D668 PCB JUMPER D0.6-P5.0 JW5.0T
D669 SCHOTTKY BARRIER DIODE ERC81-004 QDPZERC81004
D670 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D671 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D672 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D674 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D675 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D676 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D677 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D801 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D802 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D803 PCB JUMPER D0.6-P5.0 JW5.0T
D810 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D811 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D851 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D852 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1601 SCHOTTKY BARRIER DIODE ERC84-009 QDLZERC84009
ICS
IC603# PHOTO COUPLER LTV817MBF NPEBLTV817MF
IC637 IC LD1117V NSZBA0SSS046
IC801 IC POWER AMP BD5422EFS-E2 QSZBA0TRM113
IC802 IC SURROUND PROCESSOR LV1115M-TLM-E
MFP24S
QSZBA0TSY050
COILS
L661 CHOKE COIL 22µH-K LLBD00PKV021
L801 COIL RADIAL LHLP10NB330M 33µH LLF3300TU003
L802 COIL RADIAL LHLP10NB330M 33µH LLF3300TU003
L803 COIL RADIAL LHLP10NB330M 33µH LLF3300TU003
L804 COIL RADIAL LHLP10NB330M 33µH LLF3300TU003
L805 INDUCTOR 22µH-K-5FT LLARKBSTU220
L852 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q601# MOS FET 2SK3561 QFWZ02SK3561
Q602# TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q631 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q632# PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
Q633 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q635 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q636 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q637 PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
Q638# TRANSISTOR(PB FREE) KTC2026-Y/P NQEYKTC2026P
Q639 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q640 PNP TRANSISTOR POWER 2SA1887(F) QQWZ2SA1887F
Q641 TRANSISTOR 2SC2120-Y(TE2 F T) QQSY2SC2120F
Q643 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q644 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q650 TRANSISTOR(PB FREE) KTC2026-Y/P NQEYKTC2026P
Q651 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q652 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q801 TRANSISTOR(PB FREE) KTC2026-Y/P NQEYKTC2026P
Q802 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
RESISTORS
R139 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R140 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R601# METAL RES. 3W J 0.33 Ω RN03JZPZ0R33
R604 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R605 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R606 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
