Emerson LC320EM8 Service Manual

20070424 13-3 A71F3EL
R607 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R608 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R609 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R610 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R611 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R612 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R613 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R615 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R616 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R617 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R618 METAL OXIDE FILM RES. 2W J 10 Ω RN02100DP004
R619 METAL OXIDE FILM RES. 2W J 10 Ω RN02100DP004
R620 METAL OXIDE FILM RES. 2W J 1 Ω RN021R0DP004
R621 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R622 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R633 CARBON RES. 1/4W J 820 Ω RCX4JATZ0821
R634 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R635 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R636 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R639 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R641 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R642 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R643 METAL OXIDE FILM RES. 2W J 0.27 Ω RN02R27DP004
R644 PCB JUMPER D0.6-P5.0 JW5.0T
R645 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R646 CARBON RES. 1/4W J 15k Ω RCX4JATZ0153
R649 METAL OXIDE FILM RES. 1W J 100 Ω RN01101DP003
R650 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R651 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R652 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R653 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R654 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R655 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R656 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R657 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R658 CHIP RES. 1/10W F 620 Ω RRXAFR5H6200
R659 CARBON RES. 1/4W J 150 Ω RCX4JATZ0151
R660 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R661 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R662 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R663 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R664 CHIP RES. 1/10W F 39k Ω RRXAFR5H3902
R665 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R666 CHIP RES. 1/10W F 6.8k Ω RRXAFR5Z6801
R667 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R668 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R669 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R670 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R671 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R672 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R673 CARBON RES. 1/4W J 2.7k Ω RCX4JATZ0272
R675 METAL OXIDE FILM RES. 2W J 1 Ω RN021R0DP004
R676 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R677 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R678 CHIP RES. 1/10W J 6.8k Ω RRXAJR5Z0682
R679 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R680 CHIP RES. 1/10W J 1.8k Ω RRXAJR5Z0182
R681 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R682 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R683 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R684 CHIP RES. 1/10W J 56k Ω RRXAJR5Z0563
R685 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R687 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
Ref. No. Description Part No.
R688 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R689 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R690 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R691 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R692 CARBON RES. 1/4W J 33k Ω RCX4JATZ0333
R693 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R694 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R695 CARBON RES. 1/4W J 560 Ω RCX4JATZ0561
R696 CHIP RES. 1/10W J 56k Ω RRXAJR5Z0563
R800 PCB JUMPER D0.6-P12.5 JW12.5T
R801 CHIP RES. 1/10W F 100k Ω RRXAFR5H1003
R802 CHIP RES. 1/10W J 390k Ω RRXAJR5Z0394
R803 PCB JUMPER D0.6-P5.0 JW5.0T
R804 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R805 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R806 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R807 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R808 CHIP RES. 1/10W F 16.0 k Ω RRXAFR5H1602
R809 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R810 CHIP RES. 1/10W F 16.0 k Ω RRXAFR5H1602
R812 CHIP RES. 1/10W J 270k Ω RRXAJR5Z0274
R813 CHIP RES. 1/10W F 100k Ω RRXAFR5H1003
R814 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R815 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R816 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R817 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R819 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R820 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R854 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R855 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R856 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R859 CHIP RES. 1/10W J 10 Ω RRXAJR5Z0100
R860 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R863 CHIP RES. 1/10W J 3.6k Ω RRXAJR5Z0362
R864 CHIP RES. 1/10W J 3.6k Ω RRXAJR5Z0362
R865 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R866 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R869 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R870 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
B10 HEAT SINK PKH ASSEMBLY L3201UB 1EM420648
B11 HEAT SINK PKP ASSEMBLY L4200EA 1EM420855
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC602 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC632 PCB JUMPER D0.6-P5.0 JW5.0T
BC633 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC634 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC635 PCB JUMPER D0.6-P5.0 JW5.0T
BC1602 PCB JUMPER D0.6-P5.0 JW5.0T
FC601 CORE FERRITE TOROIDAL HF40T18X10X10 XL04018TE001
JS612 PCB JUMPER D0.6-P7.5 JW7.5T
JS632 PCB JUMPER D0.6-P15.0 JW15.0T
JS802 PCB JUMPER D0.6-P5.0 JW5.0T
JS803 PCB JUMPER D0.6-P5.0 JW5.0T
L6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
T601# TRANS POWER 7711 LTT3PC0KT025
Ref. No. Description Part No.
