Emerson LC320EM8 Service Manual

20070424 13-4 A71F3EL
FUNCTION CBA
IR SENSOR CBA
JACK CBA
Ref. No. Description Part No.
FUNCTION CBA(MPS-2)
Consists of the following:
----------
CAPACITORS
C108 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C110 ZENER DIODE EDZTE61 5.6B QD1B00EDZ5R6
CONNECTOR
CN102 CONNECTOR PRINT OSU S6B-PH-K-
S(LF)(SN)
J3PHC06JG030
RESISTORS
R118 PCB JUMPER D0.6-P5.0 JW5.0T
R119 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R120 CHIP RES. 1/10W J 6.8k Ω RRXAJR5Z0682
R121 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R122 CHIP RES. 1/10W J 2.7k Ω RRXAJR5Z0272
R123 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R124 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R125 CARBON RES. 1/4W J 220 Ω RCX4JATZ0221
R126 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
SWITCHES
SW108 TACT SWITCH SKQSAB SST0101AL038
SW109 TACT SWITCH SKQSAB SST0101AL038
SW110 TACT SWITCH SKQSAB SST0101AL038
SW111 TACT SWITCH SKQSAB SST0101AL038
SW112 TACT SWITCH SKQSAB SST0101AL038
SW113 TACT SWITCH SKQSAB SST0101AL038
SW114 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
BC102 PCB JUMPER D0.6-P5.0 JW5.0T
JS101 PCB JUMPER D0.6-P5.0 JW5.0T
JS103 PCB JUMPER D0.6-P5.0 JW5.0T
Ref. No. Description Part No.
IR SENSOR CBA(MPS-3)
Consists of the following:
----------
CAPACITORS
C101 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C102 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C105 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C106 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C107 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
CONNECTOR
CN001 PH CONNECTOR SIDE 8P S8B-PH-K-
S(LF)(SN)
J3PHC08JG030
DIODES
D101 LED L-53HT NP4Z000L53HT
D102 LED 333GT/E NPHZ00333GTE
RESISTORS
R101 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R102 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R103 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R104 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R105 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
MISCELLANEOUS
BC101 PCB JUMPER D0.6-P5.0 JW5.0T
RCV891 PHOTO LINK MODULE KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
JACK CBA(MPS-4)
Consists of the following:
----------
CAPACITORS
C7001 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C7002 CHIP CERAMIC CAP.(2125) F Z 10µF/10V CHE1AZ30F106
C7003 CHIP CERAMIC CAP.(2125) F Z 10µF/10V CHE1AZ30F106
C7004 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7005 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7006 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7007 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7008 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7009 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7010 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7012 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7013 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C7101 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C7102 CERAMIC CAP.(AX) B K 1000pF/50V CCA1JKT0B102
C7109 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7110 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7111 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C7602 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7605 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7608 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7611 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7615 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7618 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7621 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7624 CHIP CERAMIC CAP. F Z 4.7µF/16V(2012) CHE1CZ30F475
C7701 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7702 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7705 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7706 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7709 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7710 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7714 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7715 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7718 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7719 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7723 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7724 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7729 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7730 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7733 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7734 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7738 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7739 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7743 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7744 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7747 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7748 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7751 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7752 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7801 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C7802 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
CONNECTOR
CN7501 FMN CONNECTOR TOP 24P 24FMN-BTK-
A(LF)(SN)
JCFNG24JG019
IC
IC7001 IC VIDEO ANALOG INTERFACE R2A11011FP
QFP 56PIN
QSZBA0RHT066
COILS
L7802 PCB JUMPER D0.6-P5.0 JW5.0T
