Emerson LC320EM8 Service Manual

20070424 13-5 A71F3EL
MUT CBA
INVERTER CBA
L7803 PCB JUMPER D0.6-P5.0 JW5.0T
RESISTORS
R7001 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7002 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7101 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7102 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7103 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7104 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7105 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R7106 CHIP RES.(1608) 1/10W 0 Ω RRXAJR5Z0000
R7111 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7112 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7502 PCB JUMPER D0.6-P5.0 JW5.0T
R7503 PCB JUMPER D0.6-P5.0 JW5.0T
R7504 PCB JUMPER D0.6-P5.0 JW5.0T
R7601 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7602 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7604 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7605 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7607 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7608 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7610 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7611 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7613 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7614 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7616 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7617 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7619 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7620 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7622 CHIP RES. 1/10W J 43k Ω RRXAJR5Z0433
R7623 CHIP RES. 1/10W J 27k Ω RRXAJR5Z0273
R7701 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7702 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7708 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7709 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7715 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7716 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7723 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7724 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7730 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7731 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7738 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7739 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7747 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7748 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7755 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7756 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7763 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7764 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7771 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7772 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7779 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7780 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7787 CHIP RES.(1608) 1/10W F 75 Ω RRXAFR5H75R0
R7788 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
MISCELLANEOUS
JK7701 JACK SW DIN PCB S 04 S4-16SH JYEJ040SNJ01
JK7702 JACK SW RCA PCB S RCA-347HDT-02 JYRJ030YUQ01
JK7703 JACK SW DIN PCB S 04 S4-16SH JYEJ040SNJ01
JK7704 JACK SW RCA PCB S RCA-347HDT-02 JYRJ030YUQ01
JK7711 JACK RCA PCB S 03 RCA-347HT-03 JXRJ030YUQ01
JK7712 JACK SW RCA PCB S RCA-228H(2)NI-01 JYRJ020YUQ02
Ref. No. Description Part No.
JK7713 JACK RCA PCB S 03 RCA-347HT-03 JXRJ030YUQ01
JK7714 JACK SW RCA PCB S RCA-228H(2)NI-01 JYRJ020YUQ02
Ref. No. Description Part No.
MUT CBA
Consists of the following
1FSA10280
INVERTER CBA
JUNCTION CBA
----------
----------
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
----------
CAPACITORS
C501# ALUMINUM ELECTROLYTIC CAP 470µF/200V
M
CA2D471NC190
C504# METALIZED FILM CAP. 0.47µF/250V CT2E474MS037
C505# METALIZED FILM CAP. 0.47µF/250V CT2E474MS037
C510 FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C511 CERAMIC CAP.(AX) B J 390pF/50V CCA1JJT0B391
C512 CERAMIC CAP.(AX) B J 100pF/50V CCA1JJT0B101
C513 CERAMIC CAP.(AX) F Z 0.1µF/50V CCA1JZTFZ104
C514 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C515 PCB JUMPER D0.6-P5.0 JW5.0T
C516 CAP METALIZED FILM 0.047µF 630V J CT2K473DT036
C517 CERAMIC CAP. R K 1000pF/2KV CCD3DKA0R102
C520 FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C551 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C555 CERAMIC CAP. B K 1000pF/500V CCD2JKS0B102
C556 FILM CAP.(P) 0.01µF/50V J CA1J103MS029
C558# CAP ELE STD-85 4700µF/35V SL CE1GMZNDL472
C560 ELECTROLYTIC CAP. 0.1µF/50V M CE1JMASDL0R1
C561 CAP ELE STD-85 4700µF/35V SL CE1GMZNDL472
C1000 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1002 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1003 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1004 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1005 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C1006 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C1007 CHIP CERAMIC CAP. CH J 330pF/50V CHD1JJ3CH331
C1008 CHIP CERAMIC CAP. F Z 2.2µF/10V CHD1AZ30F225
C1009 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1010 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1011 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1012 CHIP CERAMIC CAP.(1608) B K 0.47µF/10V CHD1AK30B474
C1013 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1014 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1015 ELECTROLYTIC CAP. 470µF/35V M CE1GMZNDL471
C1016 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1017 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1018 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1019 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1020 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1021 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1032 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C1040 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1044 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1046 CHIP CERAMIC CAP.(1608) B K 1µF/25V CHD1EK30B105
C1061 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1062 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1063 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
Ref. No. Description Part No.
