Emerson LC320EM8 Service Manual

20070424 13-6 A71F3EL
C1064 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1065 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1066 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1067 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1100 ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C1101 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1102 ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C1103 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1104 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1105 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1106 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1107 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1111 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1112 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1113 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1114 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1115 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1116 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1117 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1161 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1162 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1163 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1164 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1165 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1166 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1167 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1211 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1212 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1213 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1214 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1215 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1216 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1217 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1250 ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C1251 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1252 ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C1253 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C1254 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1255 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1256 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1257 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C1261 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1262 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1263 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1264 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1265 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1266 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1267 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1311 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1312 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1313 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1314 CAP CERAMIC HV 15pF/3.15KV/SL/J CCD3FJASL150
C1315 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1316 CHIP CERAMIC CAP. B K 2200pF/50V CHD1JK30B222
C1317 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1500 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1502 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1550 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
C1552 CHIP CERAMIC CAP.(1608) B K 0.22µF/25V CHD1EK30B224
CONNECTORS
CN501 CONNECTOR B2P3-VH(LF)(SN) J3VH020JG001
CN1050 CONNECTOR/JACK 1747386-1 JB17J02AP002
Ref. No. Description Part No.
CN1100 CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1150 CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1200 CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1250 CONNECTOR/JACK 1747386-1 JB17J02AP002
CN1300 CONNECTOR/JACK 1747386-1 JB17J02AP002
DIODES
D502# DIODE 1N5406 NDLZ001N5406
D503# DIODE 1N5406 NDLZ001N5406
D504# DIODE 1N5406 NDLZ001N5406
D505# DIODE 1N5406 NDLZ001N5406
D507 DIODE 1ZC30(Q) QDLZ001ZC30Q
D509 DIODE FR154 NDLZ000FR154
D510 SCHOTTKY BARRIER DIODE ERA81-004Q QDLZRA81004Q
D511 FAST RECOVERY DIODE FE201-6 QDLZ00FE2016
D512 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D513 DIODE 1ZC30(Q) QDLZ001ZC30Q
D552# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D553# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D555# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D556 PCB JUMPER D0.6-P5.0 JW5.0T
D557 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D558# DIODE SCHOTTKY FD867-15L QDWZFD86715L
D559 DIODE 1ZC30(Q) QDLZ001ZC30Q
D560 ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D561 PCB JUMPER D0.6-P5.0 JW5.0T
D563 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1000 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1001 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1002 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1003 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1004 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1005 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1006 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1021 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1042 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D1043 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1045 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D1046 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1060 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1061 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1062 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1063 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1064 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1065 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1066 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1067 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1068 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1110 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1111 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1112 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1113 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1114 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1115 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1116 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1117 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1118 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1160 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1161 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1162 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1163 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1164 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1165 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Description Part No.
