Emerson LC320EM8 Service Manual

20070424 13-8 A71F3EL
R1040 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R1041 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1042 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1043 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R1045 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1046 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1047 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1048 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1050 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R1051 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R1052 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1053 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1060 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1061 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1062 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1063 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1064 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1065 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1066 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1067 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1068 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1069 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1070 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1071 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1100 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1101 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1102 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1103 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1104 PCB JUMPER D0.6-P5.0 JW5.0T
R1105 PCB JUMPER D0.6-P5.0 JW5.0T
R1110 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1111 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1112 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1113 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1114 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1115 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1116 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1117 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1118 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1119 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1120 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1121 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1160 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1161 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1162 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1163 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1164 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1165 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1166 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1167 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1168 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1169 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1170 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1171 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1210 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1211 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1212 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1213 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1214 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1215 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1216 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1217 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1218 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
Ref. No. Description Part No.
R1219 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1220 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1221 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1250 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1251 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1252 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1253 CHIP RES. 1/10W J 33 Ω RRXAJR5Z0330
R1254 PCB JUMPER D0.6-P5.0 JW5.0T
R1255 PCB JUMPER D0.6-P5.0 JW5.0T
R1260 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1261 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1262 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1263 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1264 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1265 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1266 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1267 CARBON RES. 1/4W J 5.1k Ω RCX4JATZ0512
R1268 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1269 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1270 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1271 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R1310 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1311 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1312 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1313 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1314 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1315 CHIP RES. 1/10W J 20k Ω RRXAJR5Z0203
R1316 CHIP RES. 1/10W F 750 Ω RRXAFR5H7500
R1317 CHIP RES. 1/10W J 5.1k Ω RRXAJR5Z0512
R1318 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1319 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R1320 CHIP RES. 1/10W J 1M Ω RRXAJR5Z0105
R1321 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1500 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1501 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1504 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1505 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1506 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1507 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1508 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1509 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1510 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1511 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1550 CHIP RES. 1/10W F 47.0 k Ω RRXAFR5H4702
R1551 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R1554 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1555 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1556 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1557 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1558 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R1559 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1560 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R1561 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R1701 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R1702 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R1703 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
MISCELLANEOUS
AC501# AC CORD W/O A GND WIRE UL 1935MM
BLACK
WAC0192LW003
B12 HEAT SINK PMI ASSEMBLY A71F0UH 1EM424257
BC501 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC502 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC552 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
