Emerson LC320EM8 Service Manual

20070424 13-9 A71F3EL
JUNCTION CBA
BC553 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1000 PCB JUMPER D0.6-P5.0 JW5.0T
BC1001 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC1050 PCB JUMPER D0.6-P12.5 JW12.5T
BC1051 PCB JUMPER D0.6-P12.5 JW12.5T
BC1100 PCB JUMPER D0.6-P10.0 JW10.0T
BC1101 PCB JUMPER D0.6-P10.0 JW10.0T
BC1150 PCB JUMPER D0.6-P12.5 JW12.5T
BC1151 PCB JUMPER D0.6-P12.5 JW12.5T
BC1200 PCB JUMPER D0.6-P10.0 JW10.0T
BC1201 PCB JUMPER D0.6-P10.0 JW10.0T
BC1250 PCB JUMPER D0.6-P10.0 JW10.0T
BC1251 PCB JUMPER D0.6-P10.0 JW10.0T
BC1300 PCB JUMPER D0.6-P10.0 JW10.0T
BC1301 PCB JUMPER D0.6-P10.0 JW10.0T
CLN552 WIRE ASSEMBLY 001 8PIN / 190MM / AWG26 WX1A71F0-001
F501# FUSE STC4A125V U/CT PAGE20CW3402
FC501 CORE FERRITE TOROIDAL HF40T18X10X10 XL04018TE001
FH501 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH502 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
GP501# GAP. FNR-G3.10D FAZ000LD6005
JS553 PCB JUMPER D0.6-P5.0 JW5.0T
JW501 PCB JUMPER D0.6-P15.0 JW15.0T
L6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA502# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T501# TRANS POWER 7715 LTT3PC0KT024
T1050 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1100 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1150 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1200 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1250 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
T1300 TRANS INVERTER ETJV23ZF2LAC LTZ2PC0MS008
Ref. No. Description Part No.
JUNCTION CBA
Consists of the following:
----------
MISCELLANEOUS
CN552 242 SERIES CONNECTOR TUC-P08X-B1 WHT
ST
JCTUB08TG002
Ref. No. Description Part No.

Emerson LC320EM8 Specifications

General

Brand	Emerson
Model	LC320EM8
Category	LCD TV
Language	English
